BRIGGS AND STRATTON VANGUARD
18HP
CRANKSHAFT:
MODEL 356447-0075-G1: 1” DIA, KEYWAY, TAPPED 3/8-24, 2-29/32” LONG
Briggs & Stratton 18 HP Vanguard V-Twin OHV Horizontal Engine. V-Twin 90° overhead valve design runs cooler, cleaner and more efficiently. More HP output with less displacement and less carbon build-up. Longer valve life and improved fuel economy. Full lubrication with spin-on oil filter cleans oil and protects engine components to ensure maximum lubrication and long life. Premium sintered iron cylinder sleeves for improved heat transfer, resulting in lower oil consumption and longer engine life. Full-length replaceable valve guides and seals extend valve life and lower oil consumption too. Commercial quality components designed and tested to meet commercial engine standards. Exceptionally quiet operation. Dual-Clean air cleaner uses pleated paper filter with foam pre-cleaner to ensure double protection for long engine life. Oil Guard Low-Oil Level Alert significantly reduces the chance of engine damage due to insufficient lubrication.
| Displacement (cc) | 570 |
| HP | 18 |
| Shaft Output | Horizontal |
| Engine Type | V-Twin OHV |
| Start Type | Electric |
| Shaft Dimensions L x W (in.) | 1 x 2 29/32 |
| Mounting Base L x W (in.) | 7.67 x 4.01 |
| Bolt Circle (in.) | 5, 6.5, 7.75 |
| PTO Height (in.) | 5.248 |
| Max. RPM | 3,600 |
| Charging System Amps | 16 |
| Ignition System | Magnetron electric |
| Oil Capacity (qt.) | 56-oz |
| Air Cleaner Type | Dual-clean element |
| Low Oil Alert | Yes |
| Lubrication System | Full pressure |
| Shaft Rotation (From PTO Shaft Side) | CCW |
| Bore x Stroke (in.) | 2.83 x 2.75 |
| Cylinder Bore | Cast iron |
| Carburetor | Fl;oat |
| Dimensions L x W x H (in.) | 12.29 x 16.10 x 17.25 |
- Briggs 18 HP Vanguard V-Twin OHV Horizontal Engine
- Magnetron Electric Ignition with 16 Amp DC Alternator
- Mechanical compression release
- Mechanical torque control
- Dual-Clean element air cleaner
- Full pressure lubrication
- Spin on oil filter
- Manual and remote choke
- Manual throttle
- Starter panel assembly
- Dual oil drain
- Does not includes muffler, exhaust manifold or fuel tank
WARRANTY
CONSUMER: 2 YEARS
COMMERCIAL: 2 YEARS
